Buchholz Indentation Hardness Tester

Brand Name BETTER UNITED
Model Number BTU
Place of Origin China
Customized support OEM, ODM, OBM
Warranty 1 Year
Delivery Time 5-8 work days
Use Coatings Paint test
Price Negotiable
Consult immediately
Detail

Buchholz Indentation Hardness Tester



Description:

Used for indentation test of single-layer or multi-layer coatings of paints and varnishes. This indenter is only used to measure the pressure

resistance of plastically deformed surfaces. When the coating film is pressed under the specified conditions with an indentation meter, the indentation length can be formed. The indentation test results are expressed as a function of the reciprocal of the indentation length. When the performance (indentation resistance) of the coating film is required to be improved, the indentation resistance value increases.


Specification:

The whole device of the indenter weighs
1000 ± 5g
The effective load on the indenter weighs
500 ± 5g;
Reading microscope
20 times magnification
Attached light source
the incident angle of the light source is greater than 60 °
Reading accuracy
0.1mm.
