Fineness Gauge
Description:
The double groove fineness plate is a fineness plate with two grooves. The surface is represented by three scales of micrometer, Hegeman and mil. The brand name and product number of Pushen are engraved on the side of the double groove fineness plate. The double groove fineness plate is equipped with a scraper. The outer packing box of the black hard plastic toolbox is used. The surface of the inner fineness plate is coated with rust oil and wrapped with plastic film. The packing is meticulous.The front surface roughness of the double groove fineness plate is 0.1 and the scraper roughness is 0.05.There are three types of double groove fineness plates: pu-2420, pu-2421 and pu-2422. The prepared wet film thicknesses are 0 ~ 25 microns, 0 ~ 50 microns and 0 ~ 100 microns respectively. They are made of stainless steel (40cr13 forging). They have good wear resistance. The double groove fineness plates are used to detect the fineness of particles such as paint, ink and pigment.
Specification:
