Brand Name BETTER UNITED
Model Number BTU-AO
Place of Origin China
Customized support OEM, ODM, OBM
Warranty 1 Year
Delivery Time 5-8 work days
Use Asphalt Bitumen Test
Price Negotiable
Consult immediately
Detail

Asphalt oven



Description:

The asphalt film oven (referred to as Type 82 oven for short) is designed and manufactured in accordance with the requirements of T 0609-2011 "Asphalt Film Heating Test" in the industrial standard JTG E20-2011 "Test Specification for Asphalt and Asphalt Mixture in Highway Engineering" of the People's Republic of China. It is applicable to measuring the mass loss after heating the asphalt film on the road, and measuring the penetration, softening point Change of brittleness and ductility to evaluate the aging resistance of asphalt.


Specification:

Working power supply
AC 220V ± 10%, 50Hz
Rated power
2.5kw
Working room temperature
163 ℃± 0.5 ℃
Temperature control accuracy
± 0.5 ℃
Rotary table speed
5.5 r/min ± 1 r/min
Number of samples
4
Studio size
450mm × 450mm × 510mm (Long × wide × High)
Ambient temperature
(5~50) ℃
Weight
50kg
