Brand Name BETTER UNITED
Model Number TYPE 85
Place of Origin China
Customized support OEM, ODM, OBM
Warranty 1 Year
Delivery Time 5-8 work days
Use Asphalt Bitumen Test
Price Negotiable
Consult immediately
Detail

Asphalt oven TYPE 85



Description:

The asphalt rotary film oven (referred to as 85 oven for short) is designed and manufactured in accordance with the requirements of T 0610-2011 Asphalt Rotary Film Heating Test in the industry standard JTG E20-2011 Test Specification for Asphalt and Asphalt Mixture in Highway Engineering of the People's Republic of China. It is applicable to determine the mass loss of the road asphalt rotating film after heating. The changes of the penetration, viscosity, ductility and brittleness of the asphalt residue after the rotary film heating are measured as required to evaluate the aging performance of the asphalt.


Specification:

Voltage
220V ± 10%
Frequency
50Hz
Total power
3.2Kw
Air supply
4000ml/min
Rotary table speed
15 r/min
Sample bottles can be filled
8
Service temperature
163 ℃± 0.5 ℃
Studio size
400×470×440mm
Instrument size
71x62x88 (cm)
Weight
60kg
