Universal Testing Machine Computer Hydraulic

Universal Testing Machine Computer Hydraulic

Standards:

EN ISO 6892-1, EN ISO 15630-1, EN ISO 7500-1, EN 10002, ASTM A370, UNI 7676

Description:

Computer hydraulic universal testing machine is designed to serve the requirements of laboratories, research and development, quality control, manufacturers and educational fields. This system are suitable to test various metallic and non-metallic materials , to determine tension, compression, bending shear strength and to determine compression and flexure strength on concrete.

Features:

l Four to six column providing superior axial and lateral stiffness and precision alignment

l Two different work spaces, the upper one for tension and the lower one for compression, bending and shearing, for a comfortable test execution

l High precision load cell, class 1 and class 0.5 calibration

l Digital displacement transducer for the best positioning and measuring accuracy

l User friendly remote for Multifunctional control

l Hydraulic jaws, for stronger clamping of the specimens

l Overload protection limit sensor

l Long piston stroke for the most convenient and easy adjustment and testing of different sample lengths

l Easy calibration procedure

l Remote control via software, text execution, data analysis available

l Software updates and modification installation available via email or remote support

l Diverse and robust configurations for test end options, graph options, PID values, crosshead movement speeds etc

l Different Testing Methods including cyclic, creep, relaxation, keeping etc

l View data and graphs of ran tests

l Determine and analyze data points such as yield point, breaking point, modulous etc

l Test report printing options include direct to printer or excel file export

l Test report data can be configured to show only necessary data and to exclude unused data

l Raw data analysis for detailed test data

l Exportable to excel and customizable to show user required data
