Detail
Laboratory Jaw Crusher Small PE
Standard:
ASTM C289 UNE 83 120 COMPARABLE TO EN 933-3 UNE 83 120 COMPARABLE TO EN 933-6
Description:
Two jaws of manganese steel are provided in this laboratory Jaw Crusher. The moveable jaw produces two blows for every revolution, thus reducing over sizing to a minimum. A combination of forward and downward strokes with a rocking action exerts pressure on the coarser material, yet permits the fi nished material to pass through the jaws.
Specification:
Opening | 100*60mm |
Max feeding size | 45mm |
Discharge opening | 6-10mm |
Capacity | 230-400kg/hour |
Rotation speed | 1400rpm |
Power | 380V,1.5kw |
Dimension | 375*350*398mm |
Weight | 150kg |
