Hand-held strain gauge

Hand-held strain gauge

Description:

The handheld strain gauge is suitable for all kinds of building structures in the long-term process of deformation, whether it is the measurement of component deformation in the manufacturing process, or the observation of structure deformation in the test process, the instrument can be used. Used for testing structural deformation in field and field. For the related research, design and construction departments and laboratories for experimental research and engineering testing.

Structure:

metal support, displacement meter (dial gauge or micrometer), telescopic adjustment part.

Structural features:

It is simple in structure, light in weight and large in range. This instrument is suitable for all kinds of building structures in the long-term process of deformation, whether it is deformation measurement in the process of component production, or structure deformation observation in the test process, can use this instrument, it is especially suitable for field and field structural deformation test.

Main technical parameters:

1. Base distance: 250mm

2. Displacement meter range: 5mm

3. Minimum scale: 40

4, standard stitch feet linear expansion coefficient alpha 1.5 x 10-6 / ℃

5. Overall dimension: 280 71 75mm

6. Weight: 2kg
