Concrete Rebar Corrosion Detector

Concrete Rebar Corrosion Detector

Description:

R61 steel corrosion meter (also known as metal corrosion meter) uses electrochemical measurement method to measure the corrosion degree of steel bars in concrete. Potential method and gradient method are used for testing, permanent reference electrode, and can automatically detect the ambient temperature.

Feature:

1. Two test methods. Potential method and gradient method are suitable for different test sites.

2. Permanent reference electrode. The saturated copper sulfate solution is sealed in the reference electrode, without changing the solution before and after the test, and the operation process is simple, clean and pollution-free.

3. Automatically detect the ambient temperature. The instrument contains an automatic temperature measurement module, which can automatically test, record and display the ambient temperature at the site. No additional thermometer is required, which is convenient and fast. This function is unique to our company.

4. The instrument can set the test date. The data is saved on the test date to facilitate the user's data management.

5. Visually display the test results. The icon is used. The darker the icon is, the higher the probability of corrosion is. During the test, users can directly see the areas with serious corrosion.

6. Real USB data transmission. The test data is quickly transferred to the computer for further analysis.

7.Powerful professional Windows data analysis and processing software. The test results can be represented in the form of graphics and images (spectrograms, isolines, etc.), which can directly generate Word test reports or import data into Excel, which is convenient and fast.

Parameters:
