Geotextile Thickness Gauge
Standard:
JTG E50、ISO 9863、GB/T 13761
Description:
Used for measuring the thickness of geosynthetic materials and related products under different pressures and specified times. By using the leverprinciple and enlarging the length of the pressure arm, the thickness of the sample was tested under pressure conditions of 2kPa, 20kPa, and 200kPa in limited space and limited weight mass
Specification:
Foot area | 25cm (foot diameter: Ø 56.42mm) |
Weight of presser foot | 5N (self weight: 510.2g) |
One compression weight | 2Kpa (self weight of compression foot) |
Secondary pressure weight | 20kPa ± 0.1kPa (foot pressure rod: 509.8g) |
Triple pressing weight | 200kPa ± 1kPa (presser foot addition code: 5098.5g) |
Dial gauge | 0-25, accuracy: 0.01mm |
Micrometer | 0-10, accuracy: 0.001mm |
Dimensions | 710 × 350 × 330mm |
Weight | 38Kg |
