Geotextile Cone-drop Punch Tester



Description：

This instrument is used to determine the penetration ability of steel cones with impedance of geotextiles and related products falling from a fixed height. It characterizes the degree of damage caused by sharp stones falling on the surface of geotextiles, and its performance meets the requirements of the instrument in GB/T17630 "Dynamic perforation test for geotextiles and related products - Falling cone method" standard.


Specification:

Inner diameter of clamping ring

150 ± 0.5mm

Distance from cone tip to specimen

500 ± 2mm

Stainless steel cone

maximum diameter 50mm

Cone angle 45 degrees

Total weight 1000 ± 5g (including guide rod)

Small angle cone

mass 600 ± 5g

Instrument weight

45Kg

Dimensions

450x350x1600mm
