Coaxial double cylinder rotational viscometer

Brand Name BETTER UNITED
Model Number BTU
Place of Origin China
Customized support OEM, ODM, OBM
Warranty 1 Year
Delivery Time 5-8 work days
Use Drilling Fluid Test
Price Negotiable
Consult immediately
Detail

Coaxial double cylinder rotational viscometer



Description:

This instrument is a general coaxial cylinder up rotation viscometer. It is suitable for industrial and mining enterprises and research departments to accurately measure the viscosity of various Newtonian fluids and the rheological properties of non Newtonian fluids in the laboratory. It can be used in paint, resin, chemical fiber, mineral oil, lubricating oil, cosmetics, sugar paddle, mud, insulating materials, etc. The instrument can be placed in the laboratory for sampling and testing,It can also be held in the hand and inserted into the liquid for portable measurement.The instrument has the characteristics of small volume, light weight, rapid measurement, convenient reading and accurate indication. The rotating speed, rotor and outer cylinder are available in a variety of specifications, which can meet a wide range of measurement. The rotary drum system is made of stainless steel and has strong capacity.


Specification:

Power Supply
220V ± 22V 50Hz ± 0.5Hz
Measuring range( η )
2.8 mPa. s~1.78 × 107 mPa. s
Shear stress( τ)
27.67 Pa~21970 Pa
Shear rate (d)
1.23 S-1 ~ 996 S-1
Speed
5.6 r/min ~ 360 r/min
Reproducibility
± 1% (F.S Newtonian fluid)
Material temperature range room temperature
~ 70 ℃
Instrument weight
≤ 12 kg
Instrument power consumption
≤ 40W
Ambient temperature
+5 ℃ ~ 35 ℃
Ambient humidity
≤ 80%
