Six Speed Rotational Viscometer Optional heating jacket
It is a mechanical viscometer, which can measure rheological parameters, as well as dynamic, static shear, fluidity index, consistency coefficient and other technical parameters. The operating principle of the machine is that the drilling fluid sample is injected into the annular space between the float and the outer sleeve when the motor is used as the power. The motor drives the rotor to connect the outer sleeve to rotate at a certain speed. The outer sleeve will exert a certain torque on the float when it rotates in the sample, and the rotation is reflected on the dial by the reaction force of the torsion spring. (rotation of 1 º is equivalent to 3.68 × 10-5 N·m。） The final viscosity is calculated by the formula. Znn-d6 six speed rotational viscometer has six rotational speeds: 3R / min, 6R / min, 100r / min, 200R / min, 300r / min and 600r / min. The machine is equipped with two sets of measuring components f1.0 and f0.2 for selection.
Specification：
