Atmospheric Automatic Swell Meter CPZ-2

share
WeChat
copy Link
Facebook
Twitter
LinkedIn
Pinterest
Pinterest
Brand Name BETTER UNITED
Model Number CPZ-2
Place of Origin China
Customized support OEM, ODM, OBM
Warranty 1 Year
Delivery Time 5-8 work days
Use Drilling Fluid Test
Price Negotiable
Consult immediately
Detail

Atmospheric Automatic Swell Meter



Description：

Under normal temperature and pressure, the instrument adopts two channels for synchronous comparative measurement. Under different pressure conditions, the hydration expansion process of shale can be obtained. It provides advanced mud testing instruments for scientific research and production.


Specification:

Main technical indicators
Normal temperature and pressure
Test range
≤ 25mm
Comprehensive measurement accuracy
≤ 5% of the maximum expansion
Resolution
0.01mm
Shale weight
5g ~ 10g
Water injection volume
100ml
Mud cake pressurization
1.0 ~ 5.0mpa (as required)
Instrument structure
Host: composed of rock sample cup, liquid cup (beaker), sensor, digital display, power supply, etc.
Data sampling system: RS232 interface is used to connect with computer for calculation, recording and storage.
