Sulfate Dry Wet Cycle Test Chamber
Description:
1. Determine the sulfate resistance of concrete specimen expressed by the maximum number of dry and wet cycles it can withstand in the dry and wet cycle environment.
2. It is controlled by a Chinese LCD controller, which is easy to operate. It can record the temperature curve, cycle times, status display, data printing and other functions of the entire test process. Valves, pipelines, circulating pumps and other components are all designed with anti-corrosion. Thermal insulation rock wool board is used. Test data power-off recovery function. When the test process is stopped unexpectedly, the last operation can be continued after restart.Concrete Testing Equipment
Specification:
| Soaking time | 15 ± 0.1h (settable) |
| Solution emptying | 0.5h ± 0.05h (settable) |
| Air drying time | 0.5h ± 0.5h (settable) |
| Drying time | 6h ± 0.1h (settable) |
| Cooling time | 1h ± 0.1h (settable) |
| Total cycle time | 24 hours (settable) |
| Power supply | 220V |
| Overall power | 5Kw |
| Temperature control range in the test chamber | 80 ± 5 ℃ |
| Quantity of test blocks | 100 * 100 * 400, 18 blocks (6 groups), 100 * 100 * 100, 54 blocks (18 groups) |
| Overall size | 1450mm * 650mm * 960mm |
