Digital Concrete Penetration Apparatus
Description:
The concrete penetration resistance meter is a mechanical contact type position meter, which is suitable for measuring small displacement of concrete specimen (under compression or tension), so as to obtain some indicators of mechanical properties of the specimen.
Feature:
The design is light and beautiful. The lever principle is used to directly read the force of the measuring needle from the instrument, making the test convenient and accurate
Specification:
Test portion container (upper diameter × Lower diameter × Depth) | φ 160mm ×φ 150mm × 150mm |
| Maximum penetration force | 1000N |
| Penetration depth | 25mm |
| Penetration speed | 2.5mm/s |
| Penetration needle section | 100mm2, 50mm2, 20mm2 |
| Penetration position | 9 points in outer circle, 4 points in inner circle |
| Force measurement method | hydraulic pressure and pressure gauge |
| Minimum division value | 5N |
| Indication error | ± 10N |
