Concrete Water Impermeability Apparatus
Standard:
DIN 1048 EN 12390-8
Description:
Used to determine the depth of penetration of the water into the concrete (impermeability) under known time and pressure. the unit accepts concrete cubic, cylindrical or prismatic specimens having max. Dimensions of 150x150x150 mm.
The specimen is put into the test chamber, clamped with suitable flanges and round gaskets. A known water pressure is applied on the specimen’s surface for a known time. A manometer checks constantly the applied water pressure.Concrete Testing Equipment
Specification:
| Model | HP-40 Type |
| Motor Power | 90W |
| Power | 380V-50HZ |
| Working pressure | 4Mpa/cm2 |
| Number of specimen | 6pcs |
| Geometry of the molding | 175x185x165mm |
| Working methods | Microcomputer automatic pressurization |
| Dimensions | 1230×745×1265mm |
| Motor speed | 1400r/min |
| Weight | 250Kg |
