Compression Testing Machines with Integrated Steel Frame for Masonary UnitsBlocks

Compression Testing Machines with Integrated Steel Frame for Masonary UnitsBlocks, Cylinders And Cubes General Purpose Automatic

Standards:
EN, BS, ASTM, AASHTO

Description:
Automatic Compressıon Testıng Machines are manufactured for compression testing of masonary units/ blocks, cylinders and cubes.perform automatically compression, flexure and splitting tensile strength tests of construction materials such as concrete, cement mortar, masonary units/blocks by controlling the automatic compression / flexure testing machines.

Test cubes up to 50 mm 70.7mm 100 mm 200 mm side and cylinders up to dia. 150x300 mm dia. 100x200 mm

Features:

· Simple and convenient operation

· Stable and reliable, stable Afterburner, Pace Rate control between 1 kN to 25 kN

· Load Accuracy Class 0.5

· Tests automatically with closed loop control

· The tests can be performed by controlling the machine either on control unit or on a computer with using Software

· Load measurment with a pressure transducer

· Mute servo motor

· High precision spoke sensor

· Hydraulic pump with dual stage for rapid approach

· Welded steel walled frame with a single acting piston

· Piston return at the end of test automatically

· Maximum pressure valves to avoid machine overloading

· Limit switch for piston stroke

· Emergency stop button

· Removable transparent front and rear safety doors

· Software controlled maximum load value

Specification:
