Cement Paste Mixer Semi-Automatic
Standard:
EN 196-1 EN 196-3 EN 413-2 EN 459-2 EN 480-1 DIN 1164-5 ASTM C305 AASHTO T162
Description:
Fy-729 cement paste mixer is a new type of double rotation and double speed paste mixer manufactured according to the main technical parameters of gb3350.8. It mixes the cement and water specified in the standard and mixes them into a uniform experimental paste, which is used for measuring the water consumption of cement standard consistency, setting time and making stability test blocks. It is the equipment of cement production plants, construction units, relevant colleges and universities and laboratories of scientific research units.Cement Testing Equipment.
Specification:
| Mixing blade width: 111min |
| Connecting thread between mixing blade and blade shaft: M16 × 1 |
| Inner diameter of mixing pot × Depth: 160 × 139mm |
| Wall thickness of mixing pot: 1mm |
| Working clearance between mixing blade and mixing pot: 2 ± 1mm |
| Overall dimension: 472×280×458mm |
| Net weight: 60kg |
Speed and time of mixing blade
| Mixing speed | Revolution r/min | Rotation r/min | Primary automatic control times |
| slow | 62±5 | 140±5 | 120±2 |
| stop | 15 | ||
| fast | 125±10 | 285±10 | 120±3 |
